JL Audio XDM1000/5 5-Channel Class-D Car and Marine Subwoofer Amplifier 1000W

JL Audio  |  SKU: 169830
Model# XDM1000/5
£929.00

This is a special order item. We do not keep this item in stock. Delivery is usually within 3-5 days of placing your order.

  • Free & Next-Day Delivery Available

    Shipped with DPD. Usually within 3-5 days.

  • Hassle-Free Returns Within 30 Days

    Hassle-Free Returns Within 30 Days

  • Free & Next-Day Delivery Available

    1 Year Warranty for Peaceful Ownership

Description


The JL Audio XDM1000/5 is designed for audiophile-grade full-system amplification, combining four full-range channels with a powerful dedicated subwoofer channel in a single compact amplifier. Delivering 100 W x4 @ 2 Ω and 600 W x1 @ 2 Ω, it provides clean, dynamic power for component speakers and a subwoofer without the need for multiple amplifiers.

At the heart of the XDM1000/5 is JL Audio’s NexD™ high-speed Class D switching technology, allowing exceptional efficiency, low heat output and outstanding sound quality from a remarkably small footprint. The amplifier is equally suited to car or marine installations, thanks to its marine-grade materials, corrosion-resistant finish and dual-mode input filter for noise-free operation in challenging environments.

The onboard signal processing is highly flexible, featuring independent crossover sections for each channel group. The amplifier can be configured as a true 3-way active system, with high-pass, band-pass and low-pass filtering adjustable from 50–500 Hz, plus an x10 multiplier extending high-pass adjustment up to 5 kHz. Optional HD-RLC or MHD-RLC remote level controllers (sold separately) allow convenient control of overall output or subwoofer level from the driver’s seat or helm.

Finished in a sleek black powder-coated chassis, all controls are protected beneath a gasketed removable top cover, ensuring durability, easy setup and a clean, professional installation.

Additional Information

  • Frequency Response (Main Channels): 12 Hz - 22 kHz (+0, -1 dB)
  • Frequency Response (Subwoofer Channel): 10 Hz - 1 kHz (+0, -1 dB)
  • S/N Ratio, referred to highest rated power (Main Channels): > 104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
  • S/N Ratio, referred to 1 W: > 84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
  • Damping Factor @ 4 Ω: > 150 / 50 Hz
  • Damping Factor @ 2 Ω: > 75 / 50 Hz
  • THD+N @ Rated Power (Main Channels): < 1% @ 2 Ω per Ch.
  • THD+N @ Rated Power (Subwoofer Channels): < 1% @ 2 Ω per Ch.
  • Input Voltage Range @ RCA Inputs: 200 mV - 4 V RMS
  • Min. Copper Power / Ground Wire Gauge: 4 AWG wire
  • Fuse Rating: 80 A (AFS, AGU or MaxiFuse™)
  • Product dimensions: 374 x 52 x 180 mm
  • Net weight: 2.79 kg
